E-2000 Connector
The E-2000â„¢ Connector offers a spring-loaded shutter mechanism that protects the ferrule end-face from scratches and dust while locking out potentially eye damaging laser radiation.
- Color coded release lever
- Push-pull locking mechanism
- Shutter for eye and dust protection
- IEC 61754-14 & EN 186270 Compliant
| Parameters | Single-mode | Multimode | |
| UPC | APC | MM | |
| Standard | |||
| Typical Insertion Loss (dB) | 0.20 | 0.20 | 0.20 |
| Max Insertion Loss (dB) | 0.40 | 0.40 | 0.30 |
| Typical Return Loss (dB) | ≥50 | ≥60 | ≥25 |
| Operating Temperature (°C) | – 25 to +75 | ||
| Durability | 1000 matings | ||
| Ferrule Ø | 125μm | 127μm | |
Data Center
Medical
Wireless
FTTH
Telecommunication
Government & Defense
Yes, you will need a Compact Duplex Clip and need to replace the two Simplex Connector Levers with a Duplex Lever.
