ST Hybrid Adapters
SENKO’s ST® hybrid adapters have been deigned to precisely align the end faces of different connector systems for applications that require mating ST to SC or FC connectors.
- Rugged metal body design
- Various footprint mounts
- Standard and narrow FC keyway
| Parameters | Specifications |
| Typical Insertion Loss (dB)* | 0.10 |
| Max Insertion Loss (dB)* | 0.20 |
| Operating Temperature (°C) | -40 to +75 |
| Humidity Resistance | 95% |
| Durability | 200 matings per GR-326-Core |
* Based on Master Grade jumper to Low Loss random mating test
Data Center
Telecommunications
Medical
Test Equipment
The adapters can be used in temperatures as low as -40°C and up to 75°C.
Yes, it will work with all industry standard connectors.
